Description:

l Wattage switchable :

20W/25W/30W/35W/40W ( 1x4ft, 2x2ft )

25W/30W/35W/40W/50W ( 2x4ft )

l CCT switchable: 3500K/4000K/5000K

l 0-10v dimmable

l PF＞0.90 , CRI＞80 , THD<20%

l Input voltage: AC120-277V 50/60Hz

l Lumen : 130 Lm/W

Features:

l Solid structure, frame in ultra-lightweight aluminum.

l Non-yellowing lens.

l Wattage and CCT switchable through dip-switches.

l High-quality LEDs, provide bright and uniform lighting.

l Compatible with standard 0-10V dimmer.

Applications:

l Schools and universities ,Offices and municipal buildings ,Healthcare facilities and hospitals

Download:

SPEC data for back-lit panel retrofit kit.pdf
